    Hydraulic Cylinder Chromed Rod Surface Automatic Grinding Linishing Machine

    Ask Lasest Price
    Brand Name : Trancar Industries
    Model Number : TCM-WP
    Certification : CE/ISO
    Price : USD 9000-50000 Dollar per set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 20 sets per Month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    Hydraulic Cylinder Chromed Rod Surface Automatic Grinding Linishing Machine

    Hydraulic cylinder chromed rod grinding linishing machine

    Automatic rod grinding machine from Hefei Trancar Industries.


    Trancar Industries Model TCM-WP automatic grinding machine is design for Hydraulic cylinder chromed rod surface grinding linishing,Beside for chromed rods surface polishing,its also could for steel cylinder products surface grinding,such as it could polish steel tube pipe,Round Solid bar,hydraulic cylinder exterior surface in mechanical way.TCM-WP rod grinding machine equip with double variable frequency grinding motors both of them power is 7.5 KW.Both grinding wheels and abrasive sanding belts are available for this type automatic polishing machine.It's widely used in the fields of pharmaceutical industry,medical industry,food industry,water purification,Pressure vessel industry,Cosmetic industry,waste water treatment,Semiconductor industry,Photovoltaic industry etc.


    Hydraulic cylinder chromed rod grinding linishing machine parameter:

    Normal configuration(customer design acceptable)

    chromed rod

    Max.Diameter

    40-800 mm

    Thickness

    3-10 mm

    Length

    ≦12,000 mm

    Machine Dimension

    (L×W×H) 14500×1200×1200mm

    Rod Roller Max.Loading capacity

    1 Ton / 2 Ton / 5 Ton / 7 Ton /8 Ton for options

    Polishing Precision

    Surface roughness(Ra)

    <=0.25μm

    Production Efficiency

    Polishing working speed

    6~12 m2/h

    Input total Power

    22 kw

    Power Supply

    380V 415V / 50Hz 60HZ / 3p or Customization

    Machine Weight

    /

    3800kg

    Color

    Grey/Green/Blue/Red/Yellow Custom design

    Suitable Polishing Materials

    Abrasive sanding belts,grinding wheels.

    (flap/cloth/ emery/Nylon wheel etc)

    For option

    Water cooling system is available during polishing.

    For more Hydraulic cylinder chromed rod grinding linishing machine,please let us know your chromed rod data,best grinding linishing solution will be sent to you accordingly.#chromedrodgrindingmachine #rodlinishingmachine

    hydraulic cylinder chromed rod grinding linishing machine (6).jpg hydraulic cylinder chromed rod grinding linishing machine (5).jpg


    Packaging and delivery:

    1,Plywood case+PE Film+ Carton protection.
    2,Based on your order requirements.

    polishing machine package1.jpg
