4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine

HEFEI TRANCAR INDUSTRIES CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers

    Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers
    • Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers
    • Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers
    • Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers
    • Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers
    • Buy cheap 4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine from wholesalers

    4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine

    Ask Lasest Price
    Brand Name : Trancar Industries
    Model Number : TCM-WP
    Certification : CE/ISO
    Price : USD 9000-50000 Dollar per set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 20 sets per Month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    4m 6m 12m 15m Steel Hydraulic Cylinder Rod Piston Rod Stainless Steel Pipe Polishing Machine

    Steel hydraulic cylinder rod piston rod outer srface automatic grinding linishing machine

    Trancar Industries Model TCM-WP automatic grinding machine is design for steel hydraulic cylinder chromed rod exterior surface grinding linishing,Beside for rod surface polishing,its also could for steel cylinder pipe solid rod products

    surface grinding,such as it could polish steel tube pipe,Round Solid bar,hydraulic cylinder exterior surface in mechanical way.

    TCM-WP rod grinding machine equip with double variable frequency grinding motors both of them power is 7.5 KW.Both grinding wheels and abrasive sanding belts are available for this type automatic polishing machine.It's widely used in the fields of pharmaceutical industry,medical industry,food industry,water purification,Pressure vessel industry,Cosmetic industry,waste water treatment,Semiconductor industry,Photovoltaic industry etc.

    Steel hydraulic cylinder rod piston rod automatic grinding linishing machine main parameter:

    Normal configuration(customer design acceptable)
    Steel metal Pipe sizeMax.Diameter40-800 mm
    Thickness3-10 mm
    Length≦15,000 mm
    Machine Dimension(L W H) 14500*1200*1200 mm
    Pipe Roller Max.Loading capacity1 Ton / 2 Ton / 5 Ton / 7Ton for options
    Polishing PrecisionSurface roughness(Ra)<=0.25μm
    Production EfficiencyPolishing working speed6~12 m2/h
    Input total Power22 kw
    Power Supply380V 415V / 50Hz 60HZ / 3p or Customization
    Machine Weight/3800kg
    ColorGrey/Green/Blue/Red/Yellow Custom design
    Suitable Polishing Materials

    Abrasive sanding belts,grinding wheels.
    (flap/cloth/ emery/Nylon wheel etc)

    For optionWater cooling system is available during polishing.





    Packaging and delivery:
    Standard Export package
    1,Plywood case+PE Film+ Carton protection.
    2,Based on your order requirements.


    polishing machine package1.jpg
    Trancar Industries other polishing machinery recommend:

    Beside pipe tube exterior surface automatic polishing machine,there are
    Tank shell & head automatic polishing machine
    Pipe tube inside surface grinding equipment
    Wire rod surface automatic linishing machine
    Welded joint planishing equipments etc








    Contact Trancar Industries for more steel automatic polishing solutions & machines.
